E-Z DRILL 210B-2 SRA

$15,995

Plus Taxes & Licensing

Achieve greater efficiency when drilling on slab with the 210B-2 SRA. It’s equipped with two-gang drill system that operates simultaneously and are adjustable to drill every 12 to 36 inches on center. It also can be customized to meet wider spacing requirements. The 210B-2 SRA requires 200 cfm and fits within a 4-foot patch. It also can be configured for on-grade drilling. With its patented tri-steering system, the drill repositions quickly and moves easily.

  • There are no features available
Lower Length (A) 46 in (116.8 cm)
Lower Length (A) + (C) 100 in (254.0 cm)
Cart Length (C) 54 in (137.2 cm)
Wheel Base (D) 48 in (121.9 cm)
Width 54 in (137.2 cm)
Height (E) 39 in (99.1 cm)
Weight 1,150 lbs (522.1 kg)
Drill Distance From Corner 6 in (15.2 cm)
Drill Distance From Ground 3 in (7.6 cm)
Drill Depth (std.) 18 in (45.7 cm)
Drill Bit Diameter 5/8 in to 2 1/2 in (15.9 mm to 63.5 mm)
Distance From Wheel to Center of Bit (F) N/A
Drill Motor (pneumatic) CP 32A
Drill Motor Weight 54 lbs (24.5 kg)
Chuck Size (std.) 7/8 in x 3 1/4 in (22.2 mm x 82.6 mm)
Air Consumption (minimum) 200 cfm (5.6 m 3 /min)
Operating Pressure 90 psi (6.2 bar)
Impact (ft. lbs./blow) 36 fpb (49 J)

Vertical Position



Lower Length (A) N/A
Lower Length (A) + (C) 73 in (185.4 cm)
Cart Length (C) 54 in (137.2 cm)
Wheel Base (D) 48 in (121.9 cm)
Width 54 in (137.2 cm)
Height (E) Varies
Weight 1,150 lbs (522.1 kg)
Drill Distance From Corner N/A
Drill Distance From Ground Up to 12 in (30.5 cm)
Drill Depth (std.) 18 in (45.7 cm)
Drill Bit Diameter 5/8 in to 2 1/2 in (15.9 mm to 63.5 mm)
Distance From Wheel to Center of Bit (F) 21 1/2 in (54.6 cm)
Drill Motor (pneumatic) CP 32A
Drill Motor Weight 54 lbs (24.5 kg)
Chuck Size (std.) 7/8 in x 3 1/4 in (22.2 mm x 82.6 mm)
Air Consumption (minimum) 200 cfm (5.6 m 3 /min)
Operating Pressure 90 psi (6.2 bar)
Impact (ft. lbs./blow) 36 fpb (49 J)
MAKE: E-Z Drill
TYPE: EQUIPEMENT
CONDITION: Used
PRICE: $11,995
MODEL: 210B-2 SRA
Year: 2015
Make: E-Z DRILL
Model: 210B-2 SRA
Condition: Slightly Used
Price: $15,995
